1
Engine displacement
1100
2
Year
2020
3
Trim
SCOUT BOBBER / BOBBER TWENTY
4
Parts Catalog
FRONT BRAKE ASM., W/ABS
5
Parts Diagram
Parts Catalog
UPPER AND LOWER STEERING CLAMPS
by
BRAKES, MASTER CYL., FRONT AND REAR
FRONT BRAKE ASM., W/ABS
1
1
1
1
2
2
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
17
18
1
WASHER 10 MM COPPER
1912829
£12,72 Unit Price incl. VAT
2
BANJO BOLT; 10 MM X 1.25-6G
1910958
£11,27 Unit Price incl. VAT
3
WIREFORM BRAKE FRT
5339129
£12,72 Unit Price incl. VAT
3
ASM-LINE BRAKE FRT APE ABS
1913351
£251,18 Unit Price incl. VAT
3
ABS BRAKE LINE ASSEMBLY; FRONT
1913335
£251,18 Unit Price incl. VAT
4
SCREW
7517704
£10,14 Unit Price incl. VAT
5
SCR-SH-M10X1.25X30 8.8 ZPC
7520057
£12,72 Unit Price incl. VAT
6
ASM-CAL FR 32/30 101 ABS ADZBK [INCL. 8-12]
1913695-468
£427,02 Unit Price incl. VAT
7
MODULE ABS SVC CRUISER
2205610
£985,51 Unit Price incl. VAT
8
K-BLEEDER SET;CAL;J
2206140
£85,31 Unit Price incl. VAT
9
K-BRACKET FRCAL
2207412
£85,31 Unit Price incl. VAT
10
K-REBUILD FRCAL 32/30
2208280
£150,71 Unit Price incl. VAT
11
BRAKE PADS
2206139
£88,60 Unit Price incl. VAT
12
SPRING AND PINS KIT
2206141
£78,74 Unit Price incl. VAT
13
K-BOOT CAL J
2206142
£53,69 Unit Price incl. VAT
14
RETAINER-BRAKE LINE CORNER
5456346
£11,57 Unit Price incl. VAT
14
RETAINER-BRAKE LINE CORNER
5455332
£9,01 Unit Price incl. VAT
15
RETAINER-BRAKE LINE BACKBONE
5455333
£9,01 Unit Price incl. VAT
16
ROUTING CLIP
7081496
£6,76 Unit Price incl. VAT
17
CLIP-BRAKE TWO-WAY
5455212
£6,55 Unit Price incl. VAT
18
ASM BLEEDER BANJO O-RING
1913696
£50,27 Unit Price incl. VAT

Find the detailed FRONT BRAKE ASM., W/ABS INDIAN diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original INDIAN part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
