REAR SUSPENSION ASM., SWING ARM AND SHOCK for INDIAN SPRINGFIELD from 2016

REAR SUSPENSION ASM., SWING ARM AND SHOCK

1

ROCKER ASSEMBLY

1019402

£353,95 Unit Price incl. VAT

2

ROCKER PIVOT

5138483

£65,29 Unit Price incl. VAT

3

SEAL

3610096

£14,69 Unit Price incl. VAT

4

THRUST BEARING

3514836

£5,24 Unit Price incl. VAT

5

NEEDLE ROLLER BEARING

3514544

£29,38 Unit Price incl. VAT

6

RING-RET INT 1 IN

7710509

£12,72 Unit Price incl. VAT

7

ROCKER BEARING

3514796

£77,56 Unit Price incl. VAT

8

SCR-HEXHD-M10X60 SPECIAL

7519902

£12,72 Unit Price incl. VAT

9

HEX NUT; 10 MM X 1.5 MM

7547746

£3,92 Unit Price incl. VAT

10

PISTON

*******

Not Available

11

NUT JAM M14X1.5

7547148

£6,76 Unit Price incl. VAT

12

NUT-JAM M18X1.5 ZC

7547693

£12,72 Unit Price incl. VAT

13

SPHERICAL FLANGE BEARING; 10 X 26 X 25

3514918

£44,06 Unit Price incl. VAT

14

ASM. PUSHROD

1019378-329

9999999

Not Available

15

SCR-HEXHD-M10X1.0X40 ZNC SPC

7519994

£29,38 Unit Price incl. VAT

16

SCR-HH-M10X1.5X55 10.9 ZPB SPC

7520325

£6,76 Unit Price incl. VAT

17

SWINGARM GUSSET PLATE; RIGHT

5257941

9999999

Not Available

18

SWINGARM GUSSET PLATE

5257205

£57,44 Unit Price incl. VAT

19

SWING ARM JT BLACK

5139825-626

£1 212,48 Unit Price incl. VAT

20

NUT-M18X1.5 NYLOCK ZPC

7547685

£12,72 Unit Price incl. VAT

21

PVOT SPACER OUTER LEFT

5138622

£29,38 Unit Price incl. VAT

22

PIVOT SPACER; LEFT

5138419

£24,48 Unit Price incl. VAT

23

RING-RTNG INT 42X1.72

7670149

£10,14 Unit Price incl. VAT

24

BALL BEARING

3514414

£18,67 Unit Price incl. VAT

25

SUSPENSION PIVOT

5138420

£169,55 Unit Price incl. VAT

Find the detailed REAR SUSPENSION ASM., SWING ARM AND SHOCK INDIAN diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original INDIAN part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
